Model: EZ16
3 in 1 Multifunction Magnetic Wireless Charger – Mobile Phone Charger – Wireless Charging Stand
Charge iphone, iwatch, airpod simultaneiously
Strong Magentic Suction
Smart indicating light
Technical Parameter
| Item | Description | Parameter | Remark | |
|---|---|---|---|---|
| 1 | Technical Standard | WPC/Qi | Qi v1.3.3 and Apple watch charging standard | |
| 2 | Coil quantities | 1 Coil + 1 Coil+ 1Coil | WPC A11+A11+Watch Coil | |
| 3 | Power Supply | 9V-2.7A/12V-2A/PD/QC3.0 | Two Channel Charging+iWatch+USB-A working together | |
| 4 | Wireless Output | 15W/10W/7.5W/5W wireless charging for mobiles | Max 15W for Qi standard | |
| 2.5W wireless charging for Watch | ||||
| 3W wireless charging for Earbuds | ||||
| USB-A output 5V/1A Max | ||||
| 5 | Wireless charging range of application | QI standard receiving devices | ||
| iwatch wireless charging | ||||
| 6 | Charging Type | Electro-magnetic induction | ||
| 7 | Charging Style | one to one in active area | ||
| Wireless charging active area | 25*25 *2mm for mobile | |||
| 8 | Charging distance | 3-8mm | Distances is between RX coil and TX coil | |
| 9 | working frequency: | 110KHZ – 205KHZ， 127.7KHZ for iphone | ||
| 10 | Standby indicator | Green LED turn on for 30 seconds and then turn off | Wireless Charging for iWatch and earbuds no indicator | |
| Charging for mobile only | Blue LED breathing for 30 seconds and then turn off | |||
| Charging protected for mobile only | Blue and Green LEDs flash alternately | |||
| Mobile charged full | LEDs indicator is the same with charging status | |||
| 11 | Conversion Rate for wireless charging | up to 83% | ||
| 12 | over voltage protection | 13±0.2V | ||
| 13 | over load protection | 22W | ||
| 14 | FOD function | support | ||
| 15 | Operating temperature and humidity | –10℃ ～ 45℃ | ||
| 16 | Storage temperature and humidity | –20℃ ～ 70℃ | ||
| 17 | Product Size | L*W*H=141*109*102mm | ||
| 18 | Net Weight | 249g | ||
| 19 | Accessories | User Manual、USB-C Cable | ||
Structure diagram
Strong Magnetic Suction
15W Fast Charging vertically or horizontally
LED smart indication
Foreign Oject Detection
Color box packing
Certificate
